CNC Lathe Trainer Machine, for Engineering

Link Copied

7.10 Lac / Piece

Edit

Business Type	Manufacturer, Exporter, Supplier
Country of Origin	Made in India
Brand Name	Sinewave
Model Name/Number	VLM-T-100
Click to view more

Product Details

Maximum Turning Diameter

30 mm

Maximum Turning Length

150 mm

Spindle Size

100 mm

Spindle Motor

2 H.P DC Motor ( 300-3000 RPM)

Automatic Lubrication Points

Linear, Circular

Programmable Feed Rate

0- 800 mm/Min

Coolant System

40 Liters. ( Programmable )

Mains Supply

230 V AC, Single Phase

Product Description

With our expertise in the respective domain, we are engaged in offering CNC Lathe Trainer Kit, which is provided with table locking facility with stepper motor brakes. Known for their alarm & self diagnostic functions, these trainers can be directly linked to PC, thereby loading of program on micro-controller is not required. Besides, the trainer can also automatically detects wrong steps in programming.

Other Details:

CAD-CAM compatibility
Machine is directly linked to PC, hence loading of program on micro-controller is not required
Easy maintenance with spare card system by layman
Table Locking facility with stepper motor brakes
Powerful stepper Motors for axis control
Variable speed DC Drives for spindle with DC Motor
Burn in components test at 150% load
Rugged Machine with Ground Bed
Wear resistant Turcite coating is provided on beds
Stick slip motion is totally avoided
Powerful PC software for graphics
High speed integer interpolation system for Circular interpolation
Display of Actual Feed rate, Spindle speed in execution & simulation mode
Automatically detects wrong steps in programming
Safety Functions with Emergency Stop, Over travel Limits
Alarm & self Diagnostic Functions are Provided
